Electrophoresis Single Phase Electric Centrifugal Pump For SPA /
Swimming Pool
Centrifugal Water Pump
Description
North America Type Electrophoresis Swimming Pool Pump rugged
one-piece shell with the unobstructed water inlet and outlet to
ensure fast and strong suction and fast circulation; more stable
during operation and extended life
Humanized noise reduction design, advanced shielding technology,
low-noise operation, even at night, will not affect people's daily
rest.
Built-in motor overheating protection device to prevent motor
burnout and ensure personnel safety in the case of siesta idling
and impeller jam
Working Condition
Medium temperature:5-50℃
Ambient temperature:≤50℃
humidity:65%RH
Working pressure:0.4MPa
Production data
| Model | Volt | POWER | Rotating Speed | Maximum Lift | Maximum Flow | Insulation | Protection Grade | Gross Weight |
| KW | HP | (r/min) | (l/min) |
| ZDXD-20YM | 230V/50HZ | 1.5 | 2.0 | 2850 | 15.0 | 550 | F | IP X5 | 18.0 |
| ZDXD-20YM | 230V/60HZ | 1.5 | 2.0 | 3450 | 15.0 | 550 | F | IP X5 | 18.0 |
| ZDXD-1-1500M | 115V/60HZ | 1.5 | 2.0 | 3450 | 15.0 | 550 | F | IP X5 | 18.0 |
| ZDXD-30YM | 230V/50HZ | 2.1 | 3.0 | 2850 | 18.0 | 633 | F | IP X5 | 20.0 |
| ZDXD-30YM | 230V/60HZ | 2.1 | 3.0 | 3450 | 18.0 | 633 | F | IP X5 | 20.0 |
| ZDXD-1-2100M | 115V/60HZ | 2.1 | 3.0 | 3450 | 18.0 | 683 | F | IP X5 | 20.0 |
| ZDXD-30YM | 380V/50HZ | 2.1 | 3.0 | 2850 | 18.0 | 633 | F | IP X5 | 20.0 |
Application
Suitable for water recirculation and filtration for SPA and hot
tubs, small and medium-sized swimming pools.
Quiet running for household applications
removable strainer basket for easy cleaning and maintenance
Pump body with high quality durable glass-loaded polypropylene
Built-in thermal protector for single phase motor
Centrifugal Water Pump
Guarantee
Guarantee for one year from shipped on board date. During the
guarantee period, our company will provide free easy-damaged spare
parts for problems caused by our quality of production or raw
material, except the damageable spare parts caused by the
customer's incorrect artificial operation. In addition, after
expiration, our company provides cost spare parts for maintenance.
Our service
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services
from designing, printing to processing. Customers can provide the
design according to your request and sample making. Also, we can
advise how to make the products according to customers' target
prices.
